HMX Bad Sweetheart Linear (10 pack)

Manufacturer Introduction:
HMX, a leading name in the switch community, collaborated with Rena Labs (one of our closest partners in the industry) to create their deepest-sounding linear yet. Drawing on advanced materials and design refinements, this switch marks a bold step for HMX's enthusiast lineup.

Product Description:
The Bad Sweetheart delivers a rich, deep acoustic tone with a firm yet smooth push feel—far from muted or shrouded. The T5 spherical UPE stem, combined with a PA12 top housing and new P4 bottom housing (with minimal fiberglass), gives each keypress a satisfying thock and a solid bottom-out echo, without unwanted clack. The tight-precision molds and factory-lubed leaf, spring, stem, and bottom rails ensure excellent glide and minimal friction. This switch stands out if you're after depth and presence, not just silence.

Switch Specifications:

• Type: Linear
• Actuation Force: 45 g ±2 g
• Bottom-Out Force: 50 g ±2 g
• Pre-Travel Distance: 2.0 mm
• Total Travel Distance: 3.8 mm ±0.2 mm
• Stem Material: T5 UPE with spherical stem tip
• Top Housing Material: PA12
• Bottom Housing Material: P4 nylon (low-fiberglass)
• Spring: 22 mm KOS single-stage extended
• Mount: 5-pin PCB
• Factory Lubed: Yes (GPL105 & GPL205 on leaf, spring, stem feet, bottom rails)
• Sound Profile: Deep, rich thock—not muted, but full-bodied
• Stem Wobble: Low, thanks to tight-fit spherical stem & housing alignment
